Above Ground Pool Water Heater

LAILEY&COATES Above Ground Pool Water Heater is the perfect choice for those looking for an energy-efficient and reliable way to heat their swimming pool. It features energy saving top discharge design, allowing for an efficient and cost-effective heating solution for your pool. With its advanced inverter technology, this heat pump ensures a safe and consistent temperature for your pool all year round. Its highly efficient motor also ensures low noise levels and minimal energy consumption. Invest in a pool heater for above ground pools today and enjoy a comfortable and energy-saving swimming experience.

Working principle of Above Ground Pool Water Heater

The swimming pool heat pump uses the principle of heat pump circulation to heat the water in the swimming pool. It works through the following steps: first, the heat pump absorbs heat from the environment, usually through an air or ground source. Then, the heat pump transfers the absorbed heat to the refrigerant, causing it to evaporate into steam. Next, the steam is compressed through the compressor, causing its temperature to rise. Subsequently, the high-temperature and high-pressure refrigerant comes into contact with the swimming pool water through the condenser, releasing heat to the pool water, causing its temperature to rise. Finally, the refrigerant is depressurized through the expansion valve and enters the evaporator cycle again to continue absorbing heat. Through this cyclic process, the heater pump for above ground pool can transfer heat from the environment to the swimming pool water, achieving a heating effect。

Features Above Ground Heat Pump

· ON/OFF heat pump technology, run 100% all the time.

· Wide model range 9.5kw, 12kw,15kw, 15kw,17kw, 21kw, 30kw

· High efficiency, COP up to 8

· Vertical design- Top discharge air

· DurableABS plastic casing, UV test approval

· Blue fin exchanger

· Titanium heat exchanger in PVC shell

· Working ambient temperature from -7℃~43℃

· Setting temperature from 8℃~40℃

· Pressure gauge available

· High pressure and low pressure switch for pressure protection

· Digital control system-Automatic control after setting.

· High efficiency defrosting function

· R32 eco friendy gas

· Heating and cooling function

· It can used for pool heating, koi pond heating, spa heating, hot tub heating

· 3 Years warranty

· Accept OEM production

· Trade term: FOB, EXW, C&F

Optional

· Wifi module

· Winter cover

· Heat pump casing color

Specifiction Above Ground Pool Pump Heater

Our vertical heat pumps for above ground swimming pools model have 9kw, 13kw, 17kw, 21kw, 30kw
